74HC139 SMD Entegre Soic-16
Stok Kodu
74HC139 SMD
7,96 TL
*0,74 TL den başlayan taksitlerle!!
Saat 14:00’ a kadar vereceğiniz tüm siparişler, aynı gün sevk edilir.
74HC139 SMD görseli ve fiyatı sitemize eklenmiştir.
| Status | Discontinued |
| Logic IC Type | OTHER DECODER/DRIVER |
| Sub Category | Decoder/Drivers |
| Family | HC/UH |
| Input Conditioning | STANDARD |
| JESD-30 Code | R-PDIP-T16 |
| JESD-609 Code | e4 |
| Load Capacitance (CL) | 50 pF |
| Max I(ol) | 0.0040 Amp |
| Moisture Sensitivity Level | NOT APPLICABLE |
| Number of Functions | 2 |
| Number of Terminals | 16 |
| Operating Temperature-Min | -40 Cel |
| Operating Temperature-Max | 125 Cel |
| Output Polarity | INVERTED |
| Power Supplies (V) | 2/6 | |
| Prop. Delay@Nom-Sup | 44 ns | |
| Propagation Delay (tpd) | 44 ns | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 4.7 mm | |
| Supply Voltage-Nom (Vsup) | 5 | |
| Supply Voltage-Min (Vsup) | 2 V | |
| Supply Voltage-Max (Vsup) | 6 V | |
| Surface Mount | NO | |
| Technology | CMOS | |
| Temperature Grade | AUTOMOTIVE | |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) | |
| Terminal Form | THROUGH-HOLE | |
| Terminal Pitch | 2.54 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED | |
| Length | 21.6 mm | |
| Width | 7.62 mm |
